MAX7219 dot matrix module ( DIY )-OKY3526 – OKYSTAR

OKY3526

MAX7219 dot matrix module ( DIY )

Product Description

100% Brand New & High Quality

Module parameters:

A single module can drive a 8×8 dot matrix common cathode
Module Operating voltage: 5V
Module dimensions: length 3.2 cm X 3.2 cm wide and 1.5 cm high X
With 4 fixing screw holes, diameter 3mm, can be fixed using M3 pillars

Module with input and output interfaces, support for cascading multiple modules.

Call on Whatsapp

Share This Product

Product Details

Product Description

Description:

DIY Kits
1 single module can drive the an 8 * 8 dot matrix common cathode
2 the module Operating voltage: 5 v
The Module 3 dimensions: length 3.2 cm X 3.2 cm wide X 1.3 cm high
4 holes with four screws, the diameter of 3 mm
Five modules with input and output interfaces, support for cascading multiple modules
Wiring instructions:
1 on the left block to an input port, the an output port on the right.
2 the When the control of a single module, simple enter the port received a CPU
The When wining 3 modules cascaded output input termination CPU, the input output termination module of the first two modules of the first one, the first two modules of the termination input terminal of the three modules, and so.
