Product Model:OKYN401-17

6S 22V 6A Li-ion Lithium 18650 Battery Charge Protection Board

Product Description

1.Discharge current: 6A

2.Charging current (same port): ≤10A

3.Main circuit conduction internal resistance: ≤20mΩ

4.Charging voltage: 25.2V Product size: 128*25*1mm

Overcharge protection

1.Detection voltage: 4.25±0.025V

2.Detection delay: 100MS Release voltage: 4.15±0.1V

Over discharge protection

1.Detection voltage: 2.7±0.08V

2.Detection delay: 100MS Release voltage: 3.0±0.1V

Over current protection

1.Detection voltage: 100MV

2.Detection delay: 1000MS Current protection: 20±3A

Self-consumption

1.Working power consumption: ≤50UA

2.Sleep over discharge power consumption: ≤10UA

3.Operating temperature range: -30/+80°C
