Product Model:OKYN330-1
6S 15A 24V PCB BMS Protection Board For 6 Pack 18650 Li-ion Lithium Battery Cell Module
Product Description
1.Size: approx.50*30*2MM
2.Lamp shift maximum discharge current: 15A
3.Instantaneous discharge current: 25A
4.Charging voltage: 25.5V
5.Charging current: 15A (MAX)
6.Overcharge detection voltage: 4.28 ± 0.05V
7.Overcharge protection delay: 0.1S
8.Overcharge release voltage: 4.08 ± 0.05V
9.Over discharge detection voltage: 2.55 ± 0.08V
10.Over discharge detection delay: 0.1S
11.The over discharge release voltage: 2.9 ± 0.1V
12.Over current detection voltage: 150MV
13.Over current detection delay: 9MS
14.Over current protection current: 30 ± 3A
15.Over current protection release condition: Disconnect the load
16.Short circuit detection delay: 250uS
17.Short circuit protection Release condition: disconnect negative open
18.Main circuit conduction resistance: ≤20mΩ
19.Working current: ≤30uA
20.Sleep current (battery over discharge) ≤10uA
21.Temperature range: -30 / + 80 °
